The second-most watched half-time show in Super Bowl history saw Rihanna watched by 5m, according to data from Fox. The highly anticipated performance relied on Sennheiser’s Digital 6000 wireless microphone system and a custom chrome SKM 6000 transmitter with an MD 9235 dynamic cardioid microphone capsule.
The choice was critical, as the State Farm Arena in the greater Phoenix area is technically one of the most challenging environments for coordinating wireless frequencies.
There were more than 2000 frequencies coordinated in Phoenix over the Super Bowl weekend as dozens of simultaneous events took place in the area, including the 2023 NFL Honors Awards, various VIP events and outdoor concerts. With this, and the ever-shrinking spectrum available for wireless microphone operators, the audio engineers and frequency coordinators for this year’s broadcast had their work cut out.
‘Phoenix is a challenging city because it is the only one that officially does not have a vacant UHF TV channel. They are all allocated for broadcast, so there is very little spectrum available for wireless mics,’ says Sennheiser Director of Spectrum & Innovation, Joe Ciaudelli. ‘To make matters more complicated, although it is an indoor stadium with a retractable roof, the State Farm Arena does not provide much shielding from outside RF signals, making it vulnerable to interference.’
Ciaudelli is an industry veteran and international expert on spectrum and wireless system operations. He contributed the chapter on wireless microphones to the Audio Engineering Society (AES) Handbook and is a private sector adviser in the US delegation to the International Telecommunications Union (ITU), the United Nations’ specialised agency on information and communications
The location and circumstances made the already high-stakes Super Bowl half-time show that much more exacting for the audio professionals involved. ‘Thanks to their resourcefulness and diligent planning, the audio engineers and NFL frequency coordinators were able to combat the harsh RF environment this year by leveraging Special Temporary Authorizations (STA) via the FCC, along with some other workarounds,’ Ciaudelli says.
An STA gives licensed wireless microphone operators temporary access to frequency bands that are not permitted for wireless mics. The engineers also used channels occupied by low power or distant TV stations and clever placement of directional antennas to further attenuate unwanted TV signals, before being picked up by the wireless microphone receivers. Without this planning and resourcefulness, the entire broadcast, including Rihanna’s performance, would have been at risk of audio dropouts and interference.
Beyond safeguarding the wireless signal via the STA and directional antennae, the audio team had to be thoughtful with the choice of the wireless microphone system for Rihanna. Not only for her vocals, but also to combat the tough RF environment and establish a reliable wireless connection. Her MD 9235 microphone capsule offered sparkle on her vocals, while the Digital 6000 did the rest.
‘Not only is the Digital 6000 with the MD 9235 capsule a great sounding microphone, but it also has such good intermodulation suppression and a clean RF signal,’ Ciaudelli says. ‘This is one tool that would work in an environment where all others might fail – it is a marvel of engineering from both the RF and audio standpoints.
‘This year’s Super Bowl highlights the challenges of a lack of suitable available spectrum for wireless mics that has led STAs to be a tiresome staple at almost all professional sporting events today. Even though it is called a Special Temporary Authorization, it is becoming so routinely used that they might as well start calling them Standard Temporary Authorizations.’
As professional sporting events become more multifaceted and the wireless audio and video channel counts increase, the challenges of the spectrum crunch are set to become still more difficult to navigate.
