Resolution screenDriven by EAW’s proprietary FChart acoustics modeling software, EAW’s Resolution simulation software provides measured 3D acoustic data to accurately predict performance within a specified venue for many of the company’s line array systems.

Resolution allows users the ability to calculate the mechanical load of the array along with the acoustic interactions that occur with a multiple array setup. Environmental conditions, such as user-defined temperature and humidity, can also be factored into the calculations. Real-time mechanical analysis is preformed on each loudspeaker enclosure and flybar to display force limitations based upon the user-entered mechanical design factor. Arrays of EAW loudspeakers can be entered manually or created with embedded auto designer.

Easy-to-read venue views include side and top-down orientations, with zoom capability. Output levels are displayed by varying color using a variety of methods, including third-octave and broadband SPL, A and C weighted. The direct SPL level and actual frequency response at any point in a venue can also be viewed. Users can print reports, as well as store and recall venue and array settings with just a click of a mouse.

‘Resolution is extremely powerful and user-friendly, uses accurately measured acoustic data, performs real-time load analysis on each mechanical junction, and most importantly, displays the results in an easy-to-interpret manner,’ says EAW Principal Engineer Nathan Butler.

Further enhancements will be made to the software in the coming months, with new products being added on a regular basis. Once installed, EAW Resolution is easily and automatically updated by using the data files available from the EAW website.

More: www.eaw.com/downloads
