The Egyptian capital’s music scene for more than a decade, the Cairo Jazz Club stages home grown and visiting artist, as well as providing a showcase for new talent. Earlier in 2016, it closed its doors for its annual renovations, and has now reopened with a fresh look and a new L-Acoustics loudspeaker system.

Comprising a combination of ARCS Wide and X Series loudspeakers, the sound system was designed and installed by Heliopolis-based Audio Technology, which has been working with the Club since 2006.

‘The project presented us with some interesting challenges,’ admits Audio Technology Sales & Marketing Manager, Amir Hany.

‘The club covers 200-sq-m in an L-shape with exposed air conduits as obstacles, which makes even sound coverage difficult. It hosts a variety of musical genres on different nights, including jazz, dance, acoustic, electronic and more.’

Add to this a stage area that becomes a dancefloor on certain nights, and the venue required a sound system that can be flexible, without sacrificing quality. In response, Audio Technology designed a distributed system, using L-Acoustics 3D modelling software and the input of L-Acoustics Application Engineer Oliver Hebert.

‘Three X15 HiQ coaxial cabinets cover the dancefloor area, and can be configured in different ways depending on the position of the DJ booth, or if a live band is playing,’ Hany explains. ‘Two SB18i subs reinforce the low-frequencies and are placed on the ground, while two ARCS Wide speakers cover the larger areas just outside the dancefloor.’

Additionally, two X12 cabinets cover the bar areas on one side of the club, with the remaining side covered by a further X12 and an X8 cabinet. The system is controlled and amplified by four LA4X amplified controllers.

‘Although the total number of cabinets isn’t large, the design and set up of the system is quite complex,’ Hany says. ‘The beauty of the L-Acoustics philosophy is that it offers a clear and streamlined product line, and all cabinets have the same sonic signature. This meant that we were able to install the loudspeakers we needed for the space, knowing that they would all interact smoothly. To make everything work seamlessly, we installed an L-Net Ethernet-based network, which allowed us to give the system the flexibility it needed.

‘There is an obvious difference in Cairo Jazz Club’s sound clarity and distribution since installing L-Acoustics in the venue. We are very happy with the outcome.’

‘When it came time to update our sound system, L-Acoustics was the best choice,’ says Cairo Jazz Club’s Alexander Rizk. ‘The L-Acoustics system addresses both the challenge of our diverse line-up and the awkward shape of the room. L-Acoustics also has the clearest, most highly defined sound on the market.’
