Shure’s Axient Digital Wireless System exploits the technology of the UHF-R, ULX-D and Axient wireless systems as the company’s premier wireless mic system.

Shure Axient Digital Wireless SystemClaiming ‘exceptional audio quality, command and control, and hardware scalability’, the Axient Digital receiver is compatible with its the AD Series and ADX Series. Axient Digital ADX Series transmitters incorporate ShowLink, which provides real-time control of all transmitter parameters with interference detection and avoidance. The ADX Series also includes the first micro-bodypack with an integrated self-tuning antenna.

‘Given the increasing challenges of RF spectrum, it’s more essential than ever that users have access to a system that can deliver the critical audio inputs of a production reliably over the air,’ says Shure Category Director for Wireless Products, Nick Wood. ‘With unparalleled RF stability and spectral efficiency, Axient Digital offers users the flexibility to work in the available spectrum, whether the number of channels required is great or small.’

Key features:
• High-Performance RF – Axient Digital features true digital diversity with Quadversity receiver technology, significantly mitigating the potential for signal fades or interference that can cause dropouts. Quadversity mode allows users to place sets of diversity antennas in different zones, or double the number of antennas in a single zone, to improve RF signal-to-noise in challenging environments. High Density mode increases the maximum simultaneous system channel count from 17 to 47 per 6MHz TV band (from 23 to 63 per 8MHz TV band), while maintaining exceptional audio quality.
• Audio Quality – Using Dante and AES3, Axient Digital has a 20Hz-20kHz frequency range with a flat frequency response and accurate transient response. Axient Digital also boasts wide dynamic range, AES-256 encryption, and 2ms latency from the mic transducer to the analogue output.
• Command and Control – Axient Digital is compatible with Wireless Workbench as well as the ShurePlus Channels App for efficient control and configuration, spectrum management and frequency monitoring. The system’s Dante Cue and Dante Browse features enable high-fidelity headphone monitoring of audio output from any Dante-enabled connected device. Additionally, Axient Digital provides networked charging via a suite of smart, high-performance batteries and chargers.
• Hardware and Scalability – Axient Digital’s wide tuning range of up to 184MHz for all transmitters and receivers covers an extended range of spectrum and simplifies inventory. Dual and quad receiver options, combined with a common receiver platform supporting AD and ADX transmitters, maximize user flexibility and scalability.

Axient Digital is compatible with the Shure Battery Rack Charger (SBRC), which supports up to eight rechargeable batteries in a single, compact rack space. Providing a seamless, tour-ready battery charging and storage solution, the SBRC features an easy-to-read front panel that displays critical battery parameters, including charge status, time-to-full, and battery health indicators. When connected to a network, Shure Wireless Workbench and ShurePlus Channels software provide remote monitoring of the SBRC to track battery status.

‘Axient Digital has been designed from the ground up to overcome the challenges users encounter in a wide variety of applications – including pro touring, theatre production and television broadcasting,’ says Shure Product Manager, Michael Johns. ‘Including unique designs such as a frequency diversity handheld microphone (ADX2FD), and a unique micro-bodypack with a self-tuning internal antenna (ADX1M), Axient Digital will allow both engineers and talent alike to confidently rely on pristine digital audio in the midst of even the most challenging environments.’

The AD Series will be available in late summer 2017, and the ADX Series will be available in early 2018.
