InfoComm saw a major expansion of the JBL Pro loudspeaker line, with the debut of its Marquis Dance Club Series.
Eight models incorporate new driver configurations and enclosure designs to deliver ‘powerful, immersive sound with exceptional clarity and fidelity even at higher volume levels’.
‘JBL began offering loudspeakers for club use back in the 1970s, and JBL products helped define club sound when the industry was just beginning,’ says JBL Senior Manager of Installed Sound, Jon Sager.
‘The Marquis Dance Club Series continues this heritage of innovation with a range of purpose-designed loudspeakers that bring high-impact sound to club-goers who want to feel and hear all the excitement of the music.’
Marquis Dance Club Series:
MD1 ultrahigh-frequency module (2 x JBL Selenium ST400 super tweeters)
MD2 horn-loaded 8-inch mid-high-frequency module (2 x 2169H Differential Drive mid-frequency transducers and one 2453H-SL compression driver, 90° horizontal coverage and up 20° and down 30° vertical coverage
MD3 horn-loaded low-frequency module (2 x 2265H Differential Drive low-frequency transducers)
MD46 four-way quad-amplified full-range system (2 x 2265H 15-inch woofers, CMCD-82H mid-frequency driver, 2432H compression driver and two ST400 super tweeters; 60° x 40° coverage pattern)
MD49 four-way quad-amplified full-range system (2 x 2265H 15-inch woofers, CMCD-82H mid-frequency driver, 2432H compression driver and two ST400 super tweeters; 90° x 50° coverage pattern)
MD52 two-way, full-range system (12-inch 262H Differential Drive woofer, 2408H-1 compression driver operating into a 90° x 50° Progressive Transition horn)
MD55 two-way, full-range system (15-inch 265H Differential Drive woofer, 2408H-1 compression driver operating into a 90° x 50° Progressive Transition horn)
MD7 subwoofer (2 x 18-inch 2269H Differential Drive subwoofers with four-inch, dual-voice-coil, dual-gap Vented Gap Cooling drivers)
The MD1, MD2, MD3 and MD7 ultra-high, mid-high-frequency, low-frequency and subwoofer modules can be combined to create a complete five-way loudspeaker system that delivers extended high-frequency and a response down to 20Hz, as wel as high volume levels in large spaces.
The MD1 provides frequency response from 8kHz to beyond 20kHz, the MD2 operates from 300Hz to 20kHz, while the MD3 operates from 80Hz to 300Hz and the subwoofer is capable of generating bass down to 25Hz.
The Marquis Dance Club Series MD46, MD49, MD52 and MD55 are standalone, full-range loudspeakers that can be used in a variety of room sizes and applications.
The systems feature a distinctive grille design and system appearance, making them suited to the interior décor of high-design club environments.
JBL Marquis Dance Club Series loudspeakers incorporate a host of the company’s most advanced and proven technologies. The heavy-duty subwoofers, woofers and midrange drivers employ JBL Differential Drive technology, which uses two voice coils and two magnetic gaps rather than the single drive coil of conventional drivers. This configuration provides higher peak output with less power compression, for consistent sound quality even at high volume levels. The subwoofers use JBL Vented Gap Cooling as well as Differential Drive technology, which pumps air through the woofer’s magnetic gap and directly over and around the voice coil to provide immediate heat transfer and reduce operating temperature, further reducing power compression and enabling greater dynamic capability.
The 2453H-SL, 2432H and 2408H-1 compression drivers use lightweight neodymium magnet structures. The 2453H-SL uses a damped laminate diaphragm, facilitating smoother frequency response. All compression drivers operate in conjunction with JBL’s Progressive Transition waveguides for high efficiency, along with extremely low distortion and optimised pattern control. The Marquis Dance Club Series is built to withstand demanding professional use, with ruggedised cabinet coverings and durable metal grilles. The MD52 and MD55 offer built-in handles, pole mounts and OmniMount-compatible mounting points, as well as multiple M10 attachment points and additional installation-friendly features.
