The broadcast production division of Turner Entertainment Group has taken a second Lawo mc²90 production console. Combined with the facility’s expanded Lawo Nova73 HD router for rights-management of shared router I/O resources with the company’s original mc²90 in Audio Control Room 22 (ACR22), the console and enhanced infrastructure are expected to dramatically improve Turner Studios’ operating efficiencies.
Turner Studios provides turnkey services for film, video and audio production for all of the Turner Entertainment Networks, and has installed the second console in ACR21. The desk is configured with 48 channel faders, 16 central faders, 256 channels of AES I/O, 48 analogue inputs, and 64 analogue outputs. It has seven DSP cards supporting 448 fully-processed channels. The console’s core is tied to a Nova73 HD Madi Router with 192 channels of Madi I/O using fail-over redundant connections. For this project, the Lawo Nova 73 HD was expanded to 40 Madi I/O ports, providing access to eight sound stage/studios and other shared resources such as a 64-channel I/O Pro Tools|HD system and the other four Audio Control Rooms, which include the studio’s first mc²90 and three additional consoles. The 8000 x 8000 Nova73 HD router is currently configured for approximately 1,300 signals in and 1,000 signals out.
Studio Audio Manager Rick Perry explains that the console will be used for live sports studio shows and sports integration, including NBA, MLB, NCAA, NASCAR, PGA and broadband programming: ‘Among the numerous shows we’ll be producing here, the new system will be used in the production of NBA Gametime Live, which is the flagship programme of NBA TV,’ he says. ‘Additionally, the new system will be used for musical performance programs, talk shows, and as part of our video production facility’s live and post operations.’
Installation and wiring of the console were completed on 1 August, with the first shows using the console taped during the week of 15 August – as training for operators new to the console and a refresher for those familiar with it from ACR22 was taking place.
‘The console’s flexible work surface was particularly important to us,’ says Erinn Thorp, Senior Production Engineer at Turner Studios. ‘Its ability to function either as the central control of all channels and functions for one operator or isolated control of any of the six channel bays for productions requiring two or more operators really fit our needs. Similarly, the fully redundant console core router, as well as fully redundant connections to the control surface and to all the control surface modules was equally important. This system provides for redundant Madi connections between the consoles and the central Madi Router as well as redundant Madi connections to the local Dallis analogue I/O frames.’
‘In addition to the console’s customised monitoring section,’ Thorp continued, ‘the enhanced rights-management of shared router I/O resources—including Lawo mic preamps integrated with the Virtual Studio Manager (VSM) software and rights-management of other shared mic preamps – adds tremendous flexibility for accessing and working with the multitude of sound sources we typically encounter.’
The installation of the console and the enhancement of the router commenced last December and involved proof-of-concept demonstrations and several meetings both in Atlanta and at Lawo’s main headquarters in Germany. The mc²90 arrived in early July and, while the AES and analogue wiring was being fitted with the various connectors and tested for the Lawo system, the console’s core and surface were up-and-running. All of this preparation work made for a simple and quick transition once the existing mc²90 console in ACR22 and the Nova73 router were made available for commissioning and testing along with the console in ACR21.
‘Right from the start, the operators felt very comfortable working on the new console,’ Perry says. ‘The biggest challenge we encountered was deciding which way they wanted to execute their setups because of the console’s versatility. Furthermore, the built the rights-management system is well designed with expansion in mind, so incorporating additional hardware in the future can be handled with little or no downtime.’
